Quick Answer
To get better internet coverage, use an Orbi router as access point. First, you need to open orbilogin.com and log in. You can connect the Orbi Internet port of the Orbi router to a LAN port on the current router with the help of an Ethernet cable. After that, Open AP mode, and you can follow the given steps to extend wi-fi.
“Advanced -> Advanced Setup-> Router/AP Mode->select AP Mode-> select dynamic IP assignment-> click Apply”.
Consideration of an ‘Orbi router as access point’is a viable solution. In AP (Access Point) mode, it works with your current router but does not act like a primary router. Orbi system provides seamless wireless connectivity while your existing routing system handles functions like IP address assignment, routing, and internet connectivity.
About Orbi Router as an Access Point
Orbi Router is a central hub of a Wi-Fi system that provides high performance, but Orbi Router as an access point is a configuration that is responsible for acting like a wireless bridge, while the existing router is responsible for the management of IP assignment or traffic control to get better Wi-Fi coverage. This configuration is useful to avoid two routers’ functions on the same network while managing high performance and better internet connectivity and access.
When Should You Configure Orbi in Access Point Mode?
You may apply Orbi AP mode when:
- Your existing ISP needs you to keep its present gateway
- ISP gateway cannot be set up for bridge mode or provide better connectivity.
- You want high performance and wide Wi-Fi coverage at home.
- The existing router manages the home network but doesn’t provide strong coverage.
- To minimise issues caused by using two routers for routing functions
- To cover the Wi-Fi connection in a medium or large home
Way to configure the Orbi Router as Access Point Step by Step
| Configuration Step | Description |
| Step 1: Connect the Orbi Router to your current router | Use an Ethernet cable to connect the Orbi Internet portCurrent Router LAN port → Orbi Internet portNOTE: Your existing gateway or router should remain connected to the present internet. |
| Step 2:Connect to the Orbi Network | Link your mobile or computer system to the Orbi network To access the administration page of the Orbi network, stay connected to the Orbi network during initial configuration. |
| Step 3:Open the Login Page | Open a web browser and enter orbilogin.com or orbilogin.com.netLog in with Orbi administrator credentials (username “Admin” and Password) |
| Step 4:Open AP mode/Router | Go to Advanced.Select Advanced SetupChoose AP Mode/RouterChoose AP Mode.Advanced -> Advanced Setup-> Router/AP Mode-> AP Mode |
| Step 5:Select the IP Address Setting | You will get an option to let the existing router assign an IP address dynamically.Select the standard option‘Get dynamically from existing router’It will allow your primary router to assign an IP address to Orbi. |
| Step 6:Apply the Changes | Click the Apply option and wait for setup to finish.Reconnect to the Orbi router to check internet connectivity. NOTE: Your connection may temporarily disconnect due to Orbi’s network configuration changes. |
Orbi App to set up Orbi Access Point
The app is designed only for the initial setup, basic management, and updates. As per ‘NETGEAR’s current support documentation’, it can not be used to configure and manage the Orbi System when it is present in AP mode. Therefore, using the Orbi web interface or orbilogin.com is useful for better configuration.
Difference between Orbi Access Point vs Router Mode
| Feature | Orbi Access Point Mode | Router Mode |
| Main routing | Exiting router | Orbi |
| Wi-Fi | Orbi | Orbi |
| Assignment of IP address | Existing router | Orbi |
| ISP Gateway | Yes | Yes |
| Ethernet Connection requirements | Yes | Yes, for normal WAN connection |
| Orbi App management | Not Available | Supported depending on configuration/model |
| Advanced router system | Some features unavailable | More features available |
Orbi Router as Access Point Not Working
Check the following:
- Check the Ethernet Connection and make sure that it is connected to the Orbi.
- Confirm AP mode by logging in to the Orbi to verify AP mode
- Restart Both Devices: At first, power off your Orbi as well as your current router. Restart the router first and allow the existing router to completely reconnect. After that, restart Orbi.
- Check IP Assignment: In dynamic IP assignment, an IP address is provided by the current router to Orbi; enter it to set the internet connection. Avoid manual entry.
Orbi Access Point No Internet
- Check that your Ethernet cable is connected correctly.
- LAN port is working.
- Orbi is actually present in AP mode.
- The router’s service is working well.
- No firewall or network restriction is present
- Restart both devices to check the connection
Common Mistakes During Orbi AP Configuration
- Wrong Ethernet port selection to connect Orbi
- Router mode on
- Manual entry for IP address
- Running two routers in AP mode
- Expecting the Orbi App to manage all the routing functions after switching to Orbi AP mode.
Frequently Asked Questions
Does Orbi Access Point mode improve Wi-Fi coverage?
Yes, Orbi AP mode indeed enhances Wi-Fi coverage, but it depends on the right selection of home layout, Orbi model, and internet configuration, etc.
Can I connect Orbi to another router in Access Point mode?
Yes, you are free to use an existing Ethernet cable to connect to the Orbi router in AP mode with the help of the Orbi Web interface.
Do I need an Ethernet cable for Orbi Access Point mode?
Yes. You require an Ethernet cable for the connection to access Orbi in AP mode.
Will my Orbi satellites work in Access Point mode?
The Orbi system has been effectively designed to support a Wi-Fi system, as well as Orbi satellites, but its management options and behaviour may vary due to differences in Orbi model and present firmware.
Final Thoughts
Orbi in AP mode is a simple and effective way to extend wi-fi coverage without removing or replacing the previous router. You can use the above steps, such as opening orbilogin.com to log in, Netgear router setup, AP mode, and assigning an IP, to set this kind of configuration.
